Ultimaker S5 Ultimaker
| Buy the Ultimaker Ultimaker S5 | ||
|---|---|---|
| Seller | Shipping zones | |
| Aniwaa | Worldwide | Quote |
| Amazon Germany | Germany | Buy |
Editor's pick
| Basic specs | Price:$ 5,995 The prices we display are estimates and can differ from the actual market prices. Prices vary by resellers and countries. |
|---|---|
| Model |
Ultimaker S5
|
| Brand | Ultimaker (see all products) |
| Category | Professional |
| Topic | Large format 3D printing (see all articles) |
| Technology | Extrusion |
| Material | Thermoplastics > Engineering (PC, nylon…) |
| Build volume | 330 x 240 x 300 mm |
| Release date | 2018 |
| Country | Netherlands |
Ultimaker Ultimaker S5 review
The Ultimaker S5 is a professional desktop 3D printer made by Ultimaker, a manufacturer based in the Netherlands. This is an updated version of the successful Ultimaker 3.
Users may control their S5 from a distance thanks to the Ultimaker App and a Wi-Fi connection. There is also an onboard camera to monitor 3D prints from a distance.
Furthermore, to maximize production efficiency, it is possible to group multiple S5 3D printers together with Cura Connect.
Thanks to its closed frame and heated print bed, the S5 is compatible with a wide range of filaments. These include PLA, ABS, Nylon, and CPE as well a Polycarbonate and flexible TPU-style material.
S5 main features
- Dual extruder (up to 280°C): this enables to 3D print with two different materials simultaneously, including water-soluble support. Also, users may switch between nozzle sizes (0.8, 0.4, or 0.25 mm) to focus on speed or detail.
- Dynamic bed heating system (up to 140°C): there is a real-time feedback system to make sure the print surface maintains a consistent temperature. The aluminum print surface is removable.
- Active bed leveling: ensures flat first layers.
- NFC reader: the S5 recognizes the material it is 3D printing to automatically use specific settings.
- Start and Play system: users may pause and resume 3D prints to swap filament, for example.
Ultimaker S5 versus Ultimaker 3
There are a few differences between the S5 and the Ultimaker 3. The S5 boasts a larger build volume and higher accuracy.
The S5 also boasts additional features such as a full-color 4.7″ touchscreen and a filament detector.
Ultimaker S5 price
This large volume 3D printer for professionals is available at the manufacturer price of$5,995 and comes with a 1-year warranty.
Ultimaker S5 Pro Bundle
A bundle for professionals is available at the price of $12,000. The pack includes:
- Air Manager: it is a printer enclosure and air filtering system that sits atop the printer.
- Material Station: this closed, anti-humidity filament chamber enables the use of up to 6 filaments at a time. It is placed beneath the printer.
- An Ultimaker S5 3D printer
Discover other Ultimaker 3D printers with our comparison engine.
Ultimaker S5 Ultimaker
General |
|
|---|---|
| Model | Ultimaker S5
|
| Manufacturer | Ultimaker |
| Price The prices we display are estimates and can differ from the actual market prices. Prices vary by resellers and countries. | $ 5,995 |
| Release date | 2018 |
| Country | Netherlands |
| Status | Available |
| Category | Professional |
| Technology | Extrusion |
| Material | Thermoplastics > Standard (PLA, ABS…) Thermoplastics > Engineering (PC, nylon…) |
Performance |
|
|---|---|
| Max. build size | 330 x 240 x 300 mm |
| Max. build volume | 23.76 L |
| Max. temperatures | |
| Extruder | — |
| Build chamber | — |
| Build plate | — |
| Min. layer thickness | 0.02 mm |
| XY accuracy | 0.007 mm |
| Max. print speed | — |
Hardware |
|
|---|---|
| Dimensions | 495 × 457 × 520 mm |
| Weight | 20.6 kg |
| Nozzle diameter(s) | 0.4 mm |
| Filament diameter | 2.85 mm |
| Power input | 500 W |
Features |
|
|---|---|
| Heated build chamber | — |
| Extruder | |
| Dual extruder | Yes |
| Independent Dual Extruder (IDEX) | — |
| Multiple extruders (3+) | — |
| Pellet extruder | — |
| Full color | — |
| Conveyor belt | — |
| 5-axis | — |
| Hybrid manufacturing | — |
| Freeform (robotic arm) | — |
Connectivity |
|
|---|---|
| USB | Yes |
| Wifi | Yes |
| Bluetooth | — |
| SD card | — |
| Ethernet | Yes |
