3D printing for space

Why is 3D printing important for the space industry?

3D printing could revolutionize space exploration by helping astronauts to create objects in space and on demand: replacement parts for repairs, custom equipment for scientific experiments, and even things like food or buildings!

Indeed, while space is an extreme environment with very few exploitable raw materials, there is plenty of dust floating around. 3D printing technology allows you to build solid structures from aggregated dust and microscopic particles. The European Space Agency (ESA) is considering 3D printing their base on the moon.

As for 3D-printed meals for astronauts, NASA is funding a project of Systems and Materials Research Corporation to develop a 3D food printer, usable in zero-gravity environment.

3D printing replacement parts in space

One of the main challenges for astronauts is needing a specific replacement part they don’t have on board the space station

 A zero-gravity 3D printer

Thanks to 3D printing technology, it is now possible to manufacture spare parts in space. NASA and Made in Space are collaborating to solve that problem. The result of their experiments is the zero G 3D printer, a 3D printer that can operate in zero-gravity environment. They managed to create a ratchet wrench from a 3D file emailed from Earth to the space station. This 3D printer uses the Fused Deposition Modeling technology and can print objects in plastic.

 “Right now if something breaks, we’re completely dependent on launching a replacement from the ground. Imagine launching everything you might ever need for mission to Mars or an asteroid, it would be challenging or impossible.

Nasa project Manager Niki Werkheiser.

The 3D printed ratchet in space by the Zero G 3D printer.

Ratchet 3D printed in space by the Zero G 3D printer.

The Zero G 3D printer by Made in Space able to 3D print in space.

The Zero G 3D printer by Made in Space able to 3D print in space.

Sending a simple spare part can last several months and costs around $17,000 per kilo.

 Future evolutions

In less than a week, the 3D file of the custom ratchet was designed, sent in space and then manufactured by the 3D printer.

The next goal is to have a database of 3D files of all the parts needed in the space station, in order to save time in case one breaks.

Being able to recycle 3D printed objects that are no longer needed and reuse the 3D printing material is also a big focus.

Solving the food problem with 3D printing

 3D printing food in space

3D printers have the capacity to create a variety of products with a small amount of raw materials.

Thus, engineers found here the perfect technology for feeding astronauts on long-term space missions. NASA has invested $125,000 in SMRC, an ambitious project led by Anjan Contractor.

He succeeded in creating a 3D printer able to 3D print a pizza in space.

The different steps of the pizza's 3D printing.

The different steps of 3D printed pizza

Pizzas are ideal for 3D printer because they’re made of different layers on top of each other (great for additive technology process like 3D printing):

  • A first layer of dough is deposited on the 3D printer’s heating bed to be directly cooked
  • A second layer of water, oil and tomato powder composes the tomato sauce
  • Another layer of cheese is deposited
  • Finally animal and vegetal proteins are added to provide essential nutriments

This process allows to cook a pizza in a few minutes and according to Anjan Contractor, carbs, proteins, macro and micro nutrients stored in a special cartridge in powder form stay edible for around 30 years. This would be enough for a mission between Earth and Mars.

3D printing a lunar base

 Building a lunar habitation to ease exploration and research

Thanks to the 3D printing technology, the European Space Agency hopes it will be one day able to 3D print a base on the moon. The international studio for architecture Foster + Partner has designed such a structure in partnership with Monolite UK, which provides the 3D printer.

According to Foster + Partner, the base must be assembled around a dome built on Earth. This dome will filter gamma rays, solar radiation and meteorites impacts. On the moon, two 3D printers would finish the build and strengthen the structure by using raw materials found on the spot.

Currently, Monolite UK says that their 3D printer is able to achieve a complete base in less than two weeks. The next generation is claimed to be twice as fast as this one.

Case studies: 3D technology for spacecraft

The 3D printed thruster chamber from the European Space Agency

The ESA unveiled in June 2015 the world’s first 3D printed spacecraft thruster, including a platinum combustion chamber. The use of 3D printing had several advantages:

  • Similar performances to a traditional thruster
  • Possibility to use new build materials
  • Lower production cost and turnover
A 3D printed thruster chamber from the European Space Agency.

The world’s first 3D-printed thruster chamber.

The SpaceX rocket engine using their 3D printed oxidizer valve.

The SpaceX rocket engine using the 3D printed oxidizer valve during a test phase.

The 3D printed oxidizer valve from the Falcon 9 rocket by SpaceX

SpaceX announced in July 2014 that they had successfully 3D printed an oxidizer valve for the 1D engine, used in the Falcon 9 rocket. The oxidizer valve is a crucial part of a rocket engine: it controls the flow of liquid oxygen as it enters the engine’s combustion chamber. It took only two days to 3D print this valve, while traditional manufacturing processes take up to months to build such parts. In addition, the 3D printed valve offers some key advantages, which have led SpaceX to the decision they will 3D print all their oxidizer valves:

  • Higher overall performances versus traditional manufacturing processes
  • Higher resistance to fracture
  • Superior ductility

The SuperDraco engine by SpaceX

SpaceX announced in May 2014 that their new rocket engine, the SuperDraco, had passed all the qualification tests. The SuperDraco boasts 3D printed combustion chamber, which was 3D printed using the Direct Metal Laser Sintering process (DMLS). Elon Musk is enthusiastic about the future of additive manufacturing for the space industry: Through 3D printing, robust and high-performing engine parts can be created at a fraction of the cost and time of traditional manufacturing methods he says. “SpaceX is pushing the boundaries of what additive manufacturing can do in the 21st century, ultimately making our vehicles more efficient, reliable and robust than ever before.”

The 3D printed SuperDraco rocket engine by SpaceX

The 3D printed SuperDraco rocket engine by SpaceX.
