Production System P-1
Technology | Binder Jetting |
Material | Metal |
Topic | Large format, Metal |
Build size | 200 × 100 × 40 mm |
Release date | 2019 |
Country | United States |
Price
Approximate starting prices based on supplier-provided information and public data. Prices may vary by region, over time and do not include additional products or services (taxes, shipping, accessories, training, installation, ...).
upon request
Desktop Metal Production System P-1 overview
The Desktop Metal Production System P-1 is a metal 3D printer for low-volume series production. The Production System presents an interesting binder jetting technology that Desktop Metal calls Single Pass Jetting (SPJ).
According to Desktop Metal, costs per part for high volume production are as low as with traditional manufacturing methods. Additionally, the Single Pass Jetting (SPJ) 3D printing process delivers 3D printing speeds of up to 1,350 cc/hr (or more with the P-50 version).
Desktop Metal Production metal 3D printing technology
- Single Pass Jetting technology: Desktop Metal combines all the necessary steps for 3D printing so that whenever there is movement, 3D printing occurs. The P-1’s full-width print bar (4,000+ jetting nozzles) works in conjunction with powder spreaders to spread powder and 3D print in a single quick pass across the build area, jetting millions of droplets per second.
- High-density nesting: Parts created by the Production system are surrounded by loose powder. This enables the full use of the build envelope as well as higher productivity per build. Desktop Metal’s software arranges (nests) parts to maximize the build area in all axes.
Desktop Metal Production price
Please contact us for a quote.
Discover more additive manufacturing systems with our 3D printer comparison engine.
Production System P-1
Price
Approximate starting prices based on supplier-provided information and public data. Prices may vary by region, over time and do not include additional products or services (taxes, shipping, accessories, training, installation, ...).
upon request
Questions? Need a quote?
Desktop Metal Production System P-1 technical specifications
General | |
---|---|
Model | Production System P-1 |
Brand | Desktop Metal |
Price Approximate starting prices based on supplier-provided information and public data. Prices may vary by region, over time and do not include additional products or services (taxes, shipping, accessories, training, installation, ...). | upon request |
Release date | 2019 |
Country | United States |
Status | Available |
Topic | Large format Metal |
Category | Industrial |
Technology | Binder Jetting |
Material | Metal |
Performance | |
---|---|
Max. build size | 200 × 100 × 40 mm |
Max. build volume | 0.8 L |
Max. temperatures | |
Extruder | - |
Build chamber | - |
Build plate | - |
Min. layer thickness | 0.05 mm |
XY accuracy | - |
Max. print speed | - |
Features | |
---|---|
Heated build chamber | - |
Extruder | |
Dual extruder | - |
Independent Dual Extruder (IDEX) | - |
Multiple extruders (3+) | - |
Pellet extruder | - |
Full color | - |
Conveyor belt | - |
5-axis | - |
Hybrid manufacturing | - |
Robotic arm | - |
Connectivity | |
---|---|
USB | - |
Wifi | - |
Bluetooth | - |
SD card | - |
Ethernet | - |
Hardware | |
---|---|
Dimensions | 1770 × 2007 × 1150 mm |
Weight | 900 kg |
Nozzle diameter(s) | - |
Filament diameter | - |
